    China Rigid MH50 Material Lifting Hoist is very compact, light-weight and easy to handle. Unlimited wire rope length and therefore unlimited lifting height. Available in various models. This hoist is not only suitable for lifting loads, but also for pulling loads in any direction.

The MH50 Material Lifting Hoist is driven by a single-phase brake motor for easy and reliable use of electricity. Operated by a control pendant (2.5m cable, Up/Down/Emergency Stop), which is supplied as standard. Power supply cable length 1 meter, with CEE Form connector.

The MH50 Material Lifting Hoist can be equipped with a robust Up/Down/Emergency Stop push button remote control with a default range 500 m (in open field), 433 MHz.

The MH50 Material Lifting Hoist offers a compact portable motorised solution for lifting, pulling as well as positioning loads.

● Unlimited wire rope length and therefore unlimited lifting height

● Compact, manageable and low self-weight.

● Unique lifting capacity/self-weight ratio.

● Handle for easy carrying

● Power supply 230 VAC or 400 VAC. Can be used in any working environment.

● High strength wire rope.

● Quick and easy installation and includes a swivel eye hook

● In conformity with Machinery Directive 2006/42/CE and the European EN 292 standard.

● WLL can be increased to a maximum of 950kg using a sheaving kit


Technical Parameters

Model Capacity
kg
Lifting speed
m/min
Rope Diam
mm
Weight
kg
Power Supply
MH501 500 8.3 6.5 32 400V/3Ph/50Hz
MH501 500 8.3 6.5 32 230V/1Ph/50Hz
